A common site installation material list

As below is a common installation material list used by North America, which include cable entry boot & panel Grounding kits & grounding bars Angle adapters Coax support blocks Hardware kits Grommets Butterfly and snap-in hangers Hoisting grips Weatherproofing kits…

Thanks! You've already liked this

Self-locking Cable Clamp for 1/2, 1/2 Superflexible coaxial cable

  Self-locking cable clamp is a type clamp an easy and quick fixation to various cables of: coaxial cables, wave guides, hybrid (power) and fiber optic cables. The cables will be firmly secured, without danger of deformation, by calibrated saddles which hold them without crushing. The installer can visually control the pressure plate by the screw (pat.). 1 […]

Thanks! You've already liked this

Rubber insert for 1-3/8″ hybrid cable, used with 1-5/8″ hanger

As per customer needs, Maxdao now developed a new size rubber insert for one 1-3/8″ (34.8mm) hybrid cable. This new rubber insert are developed for coaxial, fiber or hybrid cable (such as CommScope’s fiberfeed or RFS’s HybriFlex cable) whose outer jacket diameter is between 33-35mm. The hanger grommet can be used together with 1-5/8″ snap-in, butterfly hangers or coax […]

Thanks! You've already liked this

Open weave & closed weave hoisting grip for 1-3/8″ cable

As per customer needs, Maxdao now developed new size open weave and closed weave hoisting grip for 1-3/8″ cable. The new hoisting grips are developed to hoist or support for 1-3/8″ coaxial, fiber or hybrid cable which used in FTTA site. The grips are made of SS304 wire and optimized for easy installation. And support clamps are […]

Thanks! You've already liked this

Hoisting grips for 1/2″, 7/8″, 1-1/4″ and 1-5/8″ RF cable

Hoisting grips are used widely in the telecom infrastructure installation, it is designed for hoisting or supporting coaxial, hybrid cable or fiber cable. Normally grips are used at intervals of 200 feet along the transmission line. For transmission lines whose length exceeds 200 feet, the hoisting grip should be left on the cable and tied […]

Thanks! You've already liked this
Pre-laced (closed weave) hoisting grips with support clamp

Pre-laced (closed weave) hoisting grips with support clamp

Pre-laced hoisting grips is type of hoisting grips with closed weave design which simplifies the installation than traditional open weave, lace-up type grips. The closed weave design allows the hoisting grips slip over a un-terminated end of cable of coaxial cable, elliptical waveguide, hybrid (FiberFeed, Hybriflex) or fiber cable … The grip securely tightens being pulled, […]

Thanks! You've already liked this

Bolt head styles and American standard flat washer standard

Bolt head styles name Great pictures from http://fastspecinc.com Flat washer standard & dimension   单位(UNIT):mm    规 格 Specification 内径公差 Minor Diameter 外径公差 Outside Diameter 厚度公差 Thickness Tolerance 厚度公差分解 Thickness Tolerance Disintegration USS 3/16 6.22~6.73 14.15~14.66 0.91~1.65 0.91~1.40 1.40~1.65 USS 1/4 7.80~8.31 18.47~19.02 1.30~2.03 1.30~1.65 1.65~2.03 USS 5/16 9.40~9.91 22.05~22.99 1.63~2.64 1.63~2.20 2.20~2.64 USS 3/8 11.00~11.51 […]

Thanks! You've already liked this
Lace-up (open weave) hoisting grips

Lace-up (open weave) hoisting grips

Lace-up hoisting grips offer an productive method for support coaxial, elliptical waveguide hybrid (FiberFeed, Hybriflex) or fiber cable into position and also can be used to provide additional support in location. The lace-up design let the hoisting grip can be installed even when the run has been connectorized and facilitates very simple positioning at 200 (61m) […]

Thanks! You've already liked this

High dense polyethylene (HDP) split type cable clamp

With years’ experience of cable clamp manufacturing, Maxdao can manufacture nearly full range cable clamps for single, double, triple 1/4″, 3/8″, 1/2″, 1/2 superflexible, 7/8″, 1-1/4″, 1-5/8″, RG series.. . The clamps are designed according the famous brand cable, include but not limited to Commscope / Andrew (HELIAX, RADIAX, ), RFS (CELLFLEX), Leoni (FlexLine), Acome, LS cable […]

Thanks! You've already liked this
