Copper Lug, AWG2# ,two hole 1/4”,hole spacing 3/4”,long barrel, without inspection window

  • 49
  • 49
  • 49
Material Number: 6006585
  • Copper Conductor Size: AWG2#

Copper cable lugs are designed for connecting copper cables, coils and Bus-bars. Copper Tube Terminals between 6mm2 & 800mm2 have bell entry to ensure easy entry even for flexible conductors. The absence without inspection window prevents the entry of water or moisture into the crimped joint making these terminals suitable for outdoor applications. Long barrel provides high pull-out force and increased retention for improved mechanical and electrical performance. "colour code" help choose the right connector, the colour name is also printed in order to avoid problems for those who are colour-blind.

  • 图标 ISO9001 改
  • 图标 ROHS
  • 图标 UL 改2
  • Product Classification
  • Specifications
  • Related Product Categories
  • Related Solutions
Product Classification
Material Code 6006585
Part Number
Detail Description Copper Lug, AWG 2#, two hole 1/4”, hole spacing 3/4”, long barrel, without inspection window
General Specifications
Colour Code Brown
Material Copper
Tongue Type Standard
Tongue Angle Straight
Surface Tin-plated
Inspection Window Without inspection window
 Dimensions
Dimensions 1
Bolt Size 1/4 in | 6.9 mm
Hole Spacing (H) 3/4 in |19.0 mm
Tang Width (C) 0.60 in | 15.5 mm
Barrel length (B) 1.25 in | 33.0 mm
Overall length (L) 2.98 in | 79.0 mm
Inner diameter (ID) 0.31 in | 7.9 mm
Outer diameter (OD) 0.42 in | 10.7 mm
Electrical Specifications
Rating – Maximum Voltage 35KV
Environmental Specifications
Operating Temperature -40 °C to +90°C (-40 °F to +212 °F)
Storage Temperature -40 °C to +80 °C (-40 °F to +176 °F)
Packaging and Weights
Included Lug
Packaging Quantity and UOM 1 pcs
Piece Weight 0.059 lb | 0.027 kg
Certifications
ISO 9001:2015 Designed, manufactured and/or distributed under this quality management system
RoHS Compliant
UL&CSA Compliant
