High Speed Grounding Kit,for cable 7/8”,5.0m

  • 3 6
  • 3 6
  • 3 6
Material Number: 6003137
  • Grounding Type: Framework
  • Cable Size: 7/8"

Easy and quick installation. Low contact transition resistance of maximum 20mΩ. Suitable for screen diameter of cable OD 7/8 in. Operation Temperature -40~70 ℃. Waterproof IP68.

  • 图标 ISO9001 改
  • 图标 ROHS
  • Product Classification
  • Specifications
  • Related Product Categories
  • Related Solutions
Product Classification
Material Code 6003137
Status Active
Detail Description High Speed Grounding Kit,for cable 7/8 in,5.0m,
installation accessories including
General Specifications
Bonding Conductor Jacket Material PVC
Bonding Conductor Material Copper
Bonding Conductor Wire Size 6 AWG
Grounding Strap Material Copper
Lug Type One-hole lug
Screw Material Stainless Steel
Flat washer Material Stainless Steel
Spring washer Material Stainless Steel
Nut Material Stainless Steel
Bonding Conductor Length 5.0m |196.8 in
Lug Hole Size M8
Screw Size M8*25
Electrical Specifications
Contact Transition Resistance Maximum 20mΩ
Packaging and Weights
Height, packed 180 mm |7.0 in
Width, packed 310 mm |12.2 in
Length, packed 400 mm | 15.75 in
Included Grounding kit | M8*25 screw | M8 spring washer | M8 flat washer | M8 nut
Packaging Quantity and UOM 1 Kit
Weight, gross 1.55 kg | 3.42 lb
Certifications and Compliance
ISO 9001:2015 Designed, manufactured and/or distributed under this quality management system
ROHS Compliant
